30 Years of Piano Wire
30 Years of
Piano Wire
It’s been 30 years since Samscreen became the first American company to domestically manufacture Piano Wire screens – the original clean screen – and thanks to our high-quality raw materials, innovative manufacturing processes, and same day shipping, Samscreen is recognized today as the premier source of Piano Wire screens in North America! Sourcing all of our material inputs exclusively from within North America, ensures the consistent high quality and product delivery that our many loyal customers have come to expect.
The Magic of Music Wire
The Magic of
Music Wire
Strung with actual musical grade wire, the Piano Wire screen (sometimes also referred to as a Harp Wire screen) comes by its name honestly. Music wire’s lively vibrational properties and the straight parallel wire orientation, exert a unique cutting action on the material being screened, making it the only solution for clumpy, sticky, fine, cubical materials like damp sand, or top soil. And, with the highest percentage of open area of any screen on the market, Piano Wire can outproduce long-slot woven by a factor of 5X!
Same Day Shipping!
Same Day
Shipping!
Thanks to our culture of continuous improvement and innovation, Samscreen can design and ship out your perfect fit, custom Piano Wire screen within one business day! Our record setting turn-times and relentless commitment to quality make Samscreen the industry leading supplier/partner that you can count on.
The Original Clean Screen
For high productivity screening
Piano Wire
WHEN YOUR PROBLEM IS…
Long-slot woven pegging & blinding + slow thru-put
YOUR SOLUTION IS…
The ultra fast, ultra clean cutting action of a Piano Wire screen for 5X greater productivity than woven wire
The hooks shown below are examples of common types, however, the hook shape, as well as the backleg and throat dimensions, can be customized for any machine.
Opening Size | Standard Wire | Heavy Wire | Heavy Duty Wire |
---|---|---|---|
1.2mm (3/64″) | .50mm (.020″) | .65mm (.026″) | |
1.5mm (1/16″) | .65mm (.026″) | .80mm (.031″)* | |
2mm (3/32″) | .65mm (.026″) | .80mm (.031″)* | |
3mm (1/8″) | .80mm (.031″)* | 1.0mm (.039″) | |
4mm (5/32″) | 1.0mm (.039″) | 1.2mm (.047″) | |
5mm (3/16″) | 1.0mm (.039″) | 1.2mm (.047″) | |
6mm (1/4″) | 1.2mm (.047″) | 1.4mm (.055″) | 2.0mm (.079″) |
8mm (5/16″) | 1.4mm (.055″) | 1.6mm (.063″) | 2.0mm (.079″) |
10mm (3/8″) | 1.4mm (.055″) | 1.6mm (.063″) | 2.0mm (.079″) |
12mm (1/2”) | 1.6mm (.063″) | 1.8mm (.070″)* | 2.0mm (.079″) |
16mm (5/8″) | 2.0mm (.079″) | 2.5mm (.098″) | 3.0mm (.118″) |
19mm (3/4″) | 2.0mm (.079″) | 2.5mm (.098″) | 3.0mm (.118″) |
*Only available in Carbon Wire
Screen Configuration
Tips
Maximize open area & screening productivity, while balancing sizing requirements & wear life goals – by understanding the benefits and trade-offs of each screen configuration option.
Wire
Thickness
Balance your wear life and production goals by choosing the thinnest wire your material will allow.
Wire Type
Premium Music Wire
WHEN TO USE:
Screening heavy and/or abrasive material in dry conditions – Premium Music Wire has greater impact and abrasion resistance than Stainless Steel Wire
WHEN NOT TO USE:
Screening corrosive or sticky materials – Music Wire will eventually pit and rust, compromising wear life and material thru-put
Vs.
304 Stainless Steel
WHEN TO USE:
Screening corrosive or sticky materials – Stainless Steel’s smooth non-rusting surface makes it ideal for wet, sticky, and corrosive environments, extending wear life and material thru-put
WHEN NOT TO USE:
Screening heavy and/or abrasive material in dry conditions – Music Wire has greater impact and abrasion resistance than Stainless Steel Wire
Profiles
When choosing a profile to fit your machine’s crown bars, it is important to know when crown bar rubber must be used underneath profiles to cushion screen wires. Metal to metal contact between screen wires and crown bars must be prevented to avoid wire breakage.
Round Profile
✓ Use Crown Bar Rubber
No built-in cushioning
Square Profile
✗ Do Not Use Crown Bar Rubber
Built-in cushioning
Crowned Round Profile
✓ Use Crown Bar Rubber when installed over Square Crown Bars
✗ Do Not Use Crown Bar Rubber when installed over Round Crown Bars
